AC30

Need an innovative way to reduce waste hauling costs? The AC30 not only gets the job done, it saves you money in the process.

The AC30 is ideally suited for applications in apartment buildings and is also beneficial for hospitals, nursing homes and office buildings where space is limited. The AC30 has a one-sided container connection system as a standard feature on every machine. This allows the user to easily connect and disconnect the containers to the compactor simply by pulling one lever.

Specifications subject to change without notice.

Product Number: AC30
Product Name: Apartment Compactor

The AC30 is Ideal for:

  • Small Apartments
  • Hospitals
  • Nursing Homes

The AC30’s Benefits:

  • Reduces waste disposal costs
  • Improves your business appearance and increases workplace safety
  • Saves labor and time making your operation more profitable

Height: 68.5 in (1740mm)

Width: 48 (1219mm)

Depth: 70.50 in (1791mm)

Container Capacity: 2.25 cu. yds.

Charge Size: .35 cu. yds.

Ram Pressure @ 2,000: 25,134 lbs. (11,400kg)

Ram Penetration: 6 in. (152mm)

Cycle Time: 31 seconds

Cylinder Size: 4 in. (102mm) BORE, 2 in. (51mm) ROD, 30.35 in. (768mm) STROKE

Motor: 2 HP, TEFC

Pump: Two Stage

Oil Capacity: 3 gallons

Shipping Weight: 740 lbs. (336kg)
